SIMPRO-100 Relay Settings Sheets
SIMPRO-100
216 PRIM-2400C
The balance of Thermal Element Settings are used
regardless of setting method.
Thermal Capacity Alarm Pickup
Range: 50% – 100%
TCAPU =
[90]
Thermal Capacity Used to Start
Range: 20% – 100%
TCSTART =
[85]
Use Learned Starting Thermal Capacity
Range: Y, N
TCLRNEN =
[Y]
Motor Stopped Cooling Time
Range: 180 – 72000 s
COOLTIME =
[259]
Use Learned Cooling Time
Range: Y, N
COOLEN =
[Y]
F.1.3 Overcurrent (O/C)
Elements
(Time-delay settings are
hidden when their associated pickup settings
= OFF)
Level 1 Phase O/C Pickup
Range: OFF, 0.25 – 100.00 A; ITAP = 5 A
Range: OFF, 0.05 – 20.00 A; ITAP = 1 A
50P1P =
[OFF]
Level 1 Phase O/C Time Delay
Range: 0.00 – 400.00 s
50P1D =
[Hidden]
Level 2 Phase O/C Pickup
Range: OFF, 0.25 – 100.00 A; ITAP = 5 A
Range: OFF, 0.05 – 20.00 A; ITAP = 1 A
50P2P =
[OFF]
Level 2 Phase O/C Time Delay
Range: 0.00 – 400.00 s
50P2D =
[Hidden]
Level 1 Residual O/C Pickup
Range: OFF, 0.25 – 100.00 A; ITAP = 5 A
Range: OFF, 0.05 – 20.00 A; ITAP = 1 A
50G1P =
[2.50]
Level 1 Residual O/C Time Delay
Range: 0.00 – 400.00 s
50G1D =
[0.10]
Level 2 Residual O/C Pickup
Range: OFF, 0.25 – 100.00 A; ITAP = 5 A
Range: OFF, 0.05 – 20.00 A; ITAP = 1 A
50G2P =
[OFF]
Level 2 Residual O/C Time Delay
Range: 0.00 – 400.00 s
50G2D =
[Hidden]
Level 1 Neutral O/C Pickup
Range: OFF, 0.025 – 10.000 A; INTAP = 5A
Range: OFF, 0.005 – 2.000 A; INTAP = 1 A
50N1P =
[2.500]
Level 1 Neutral O/C Time Delay
Range: 0.00 – 400.00 s
50N1D =
[0.10]
Level 2 Neutral O/C Pickup
Range: OFF, 0.025 – 10.000 A; INTAP = 5 A
Range: OFF, 0.005 – 2.000 A; INTAP = 1 A
50N2P =
[OFF]
Level 2 Neutral O/C Time Delay
Range: 0.00 – 400.00 s
50N2D =
[Hidden]
