SIMPRO-100
SIMPRO-100 Relay Settings Sheets
F
PRIM-2400C 219
RTD Location
Range: WDG, BRG, AMB, OTH, NONE
RTD6LOC =
[Hidden]
RTD Location
Range: WDG, BRG, AMB, OTH, NONE
RTD7LOC =
[Hidden]
RTD Location
Range: WDG, BRG, AMB, OTH, NONE
RTD8LOC =
[Hidden]
RTD Location
Range: WDG, BRG, AMB, OTH, NONE
RTD9LOC =
[Hidden]
RTD Location
Range: WDG, BRG, AMB, OTH, NONE
RTD10LOC =
[Hidden]
RTD Location
Range: WDG, BRG, AMB, OTH, NONE
RTD11LOC =
[Hidden]
RTD Location
Range: WDG, BRG, AMB, OTH, NONE
RTD12LOC =
[Hidden]
F.1.12 RTD Type Settings
(Hidden when
RTDOPT = NONE)
RTD Type
Range: PT100, NI100, NI120, CU10
RTD1TY =
[Hidden]
RTD Type
Range: PT100, NI100, NI120, CU10
RTD2TY =
[Hidden]
RTD Type
Range: PT100, NI100, NI120, CU10
RTD3TY =
[Hidden]
RTD Type
Range: PT100, NI100, NI120, CU10
RTD4TY =
[Hidden]
RTD Type
Range: PT100, NI100, NI120, CU10
RTD5TY =
[Hidden]
RTD Type
Range: PT100, NI100, NI120, CU10
RTD6TY =
[Hidden]
RTD Type
Range: PT100, NI100, NI120, CU10
RTD7TY =
[Hidden]
RTD Type
Range: PT100, NI100, NI120, CU10
RTD8TY =
[Hidden]
RTD Type
Range: PT100, NI100, NI120, CU10
RTD9TY =
[Hidden]
RTD Type
Range: PT100, NI100, NI120, CU10
RTD10TY =
[Hidden]
RTD Type
Range: PT100, NI100, NI120, CU10
RTD11TY =
[Hidden]
RTD Type
Range: PT100, NI100, NI120, CU10
RTD12TY =
[Hidden]
