SIMPRO-100 Relay Settings Sheets

SIMPRO-100

218 PRIM-2400C

Load-Loss Alarm Time Delay

Range: 0.00 – 400.00 s

LLADLY =

[5.00]

Load-Loss Trip Time Delay

Range: 0.00 – 400.00 s

LLTDLY =

[10.00]

F.1.7 Current Unbalance

Elements Settings

Current Unbalance Alarm Pickup

Range: OFF, 2% – 80%

46UBA =

[10]

Current Unbalance Alarm Delay

Range: 0.10 – 400.00 s

46UBAD =

[10.00]

Current Unbalance Trip Pickup

Range: OFF, 2% – 80%

46UBT =

[15]

Current Unbalance Trip Delay

Range: 0.10 – 400.00 s

46UBTD =

[5.00]

F.1.8 Phase Reversal Tripping

Setting

Enable Phase Reversal Tripping

Range: Y, N

E47T =

[Y]

F.1.9 Speed Switch Tripping

Time Delay Setting

Speed Switch Trip Time Delay

Range: OFF, 0.50 – 400.00 s

SPDSDLY =

[OFF]

F.1.10 RTD Configuration

Settings

RTD Input Option

(INT is not available if no RTD option)

Range: INT, EXT, NONE

RTDOPT =

[None]

Temperature Preference Setting

(Hidden when RTDOPT = NONE)

Range: C, F

TMPREF =

F.1.11 RTD Location Settings

(Hidden when RTDOPT = NONE)

RTD Location
