SIMPRO-100
SIMPRO-100 Relay Settings Sheets
F
PRIM-2400C 221
RTD Alarm Temperature
Range: OFF, 0° – 250°C
OFF, 32° – 482°F
ALTMP9 =
[Hidden]
RTD Trip Temperature
Range: OFF, 0° – 250°C
OFF, 32° – 482°F
TRTMP10 =
[Hidden]
RTD Alarm Temperature
Range: OFF, 0° – 250°C
OFF, 32° – 482°F
ALTMP10 =
[Hidden]
RTD Trip Temperature
Range: OFF, 0° – 250°C
OFF, 32° – 482°F
TRTMP11 =
[Hidden]
RTD Alarm Temperature
Range: OFF, 0° – 250°C
OFF, 32° – 482°F
ALTMP11 =
[Hidden]
RTD Trip Temperature
Range: OFF, 0° – 250°C
OFF, 32° – 482°F
TRTMP12 =
[Hidden]
RTD Alarm Temperature
Range: OFF, 0° – 250°C
OFF, 32° – 482°F
ALTMP12 =
[Hidden]
Enable Winding Trip Voting
Range: Y, N
EWNDGV =
[Hidden]
Enable Bearing Trip Voting
Range: Y, N
EBRNGV =
[Hidden]
Enable RTD Biasing
(Hidden if not RTDnLOC = AMB, or if
all winding RTD trip temperatures are OFF)
Range: Y, N
RTDBEN =
[Hidden]
F.2 Voltage-Based
Protection
F.2.1 Undervoltage (U/V)
Elements
(Hidden if no voltage option
or if DELTA_Y = Y)
Level 1 Phase-Phase U/V Pickup
Range: OFF, 1 – 300 V
27P1P =
[Hidden]
Level 2 Phase-Phase U/V Pickup
Range: OFF, 1 – 300 V
27P2P =
[Hidden]
F.2.2 Overvoltage (O/V)
Elements
(Hidden if no voltage option
or if DLTA_Y = Y)
Range: OFF, 1 – 300 V
59P1P =
[Hidden]
Level 2 Phase-Phase O/V Pickup
Range: OFF, 1 – 300 V
59P2P =
[Hidden]
