SIMPRO-100 Relay Settings Sheets
SIMPRO-100
222 PRIM-2400C
F.2.3 Undervoltage (U/V)
Elements
(Hidden if no voltage option
or if DELTA_Y = D)
Level 1 Phase U/V Pickup
Range: OFF, 1 – 300 V
27P1P =
[OFF]
Level 2 Phase U/V Pickup
Range: OFF, 1 – 300 V
27P2P =
[OFF]
F.2.4 Overvoltage (O/V)
Elements
(Hidden if no voltage option
or if DELTA_Y = D)
Level 1 Phase O/V Pickup
Range: OFF, 1 – 300 V
59P1P =
[73]
Level 2 Phase O/V Pickup
Range: OFF, 1 – 300 V
59P2P =
[OFF]
Residual O/V Pickup
(Hidden if SINGLEV = Y)
Range: OFF, 1 – 300 V
59GP =
[OFF]
F.2.5 Reactive Power (VAR)
Element Settings
(Hidden if no
voltage option)
Negative VAR Alarm Pickup
Range: OFF, 30 – 2000 VAR; ITAP = 5 A
OFF, 6 – 400 VAR; ITAP = 1 A
NVARAP =
[OFF]
Positive VAR Alarm Pickup
(Hidden if NVARAP = OFF)
Range: 30 – 2000 VAR; ITAP = 5 A
6 – 400 VAR; ITAP = 1 A
PVARAP =
[Hidden]
VAR Alarm Time Delay
(Hidden if NVARAP = OFF)
Range: 0.00 – 400.00 s
VARAD =
[Hidden]
Negative VAR Trip Pickup
Range: OFF, 30 – 2000 VAR; ITAP = 5 A
OFF, 6 – 400 VAR; ITAP = 1 A
NVARTP =
[OFF]
Positive VAR Trip Pickup
(Hidden if NVARTP = OFF)
Range: 30 – 2000 VAR; ITAP = 5 A
6 – 400 VAR; ITAP = 1 A
PVARTP =
[Hidden]
VAR Trip Time Delay
(Hidden if NVARTP = OFF)
Range: 0.00 – 400.00 s
VARTD =
[Hidden]
VAR Element Arming Delay
(Hidden if both NVARAP and NVARTP = OFF)
Range: 0.00 – 15000 s
VARDLY =
[Hidden]
F.2.6 Underpower Element
Settings
(Hidden if no voltage option)
Phase Underpower Alarm Pickup
Range: OFF, 30 – 2000 W; ITAP = 5 A
OFF, 6 – 400 W; ITAP = 1 A
37PAP =
[OFF]
Phase Underpower Alarm Time Delay
(Hidden if 37PAP = OFF)
Range: 0.00 – 400.00 s
37PAD =
Phase Underpower Trip Pickup
Range: OFF, 30 – 2000 W; ITAP = 5 A
OFF, 6 – 400 W; ITAP = 1 A
37PTP =
[OFF]
