SIMPRO-100 Relay Settings Sheets
F
PRIM-2400C 223
Phase Underpower Trip Time Delay
(Hidden if 37PTP = OFF)
Range: 0.00 – 400.00 s
37PTD =
[Hidden]
Underpower Element Arming Delay
(Hidden if both 37PAP and 37PTP = OFF)
Range: 0 – 15000 s
37DLY =
[Hidden]
F.2.7 Power Factor Element
Settings
(Hidden if no voltage option)
Power Factor Alarm Leading Pickup
Range: OFF, 0.05 – 0.99
55LDAP =
[OFF]
Power Factor Alarm Lagging Pickup
(Hidden if 55LDAP = OFF)
Range: 0.05 – 0.99
55LGAP =
[Hidden]
Power Factor Alarm Time Delay
(Hidden if 55LDAP = OFF)
Range: 0.00 – 400.00 s
55AD =
[Hidden]
Power Factor Trip Leading Pickup
Range: OFF, 0.05 – 0.99
55LDTP =
[OFF]
Power Factor Trip Lagging Pickup
(Hidden if 55LDTP = OFF)
Range: 0.05 – 0.99
55LGTP =
[Hidden]
Power Factor Trip Time Delay
(Hidden if 55LDTP = OFF)
Range: 0.00 – 400.00 s
55TD =
[Hidden]
Power Factor Element Arming Delay
(Hidden if both 55LDAP and 55LDTP = OFF)
Range: 0 – 15000 s
55DLY =
[Hidden]
F.2.8 Frequency Elements
Settings
(Hidden if no voltage option)
Level 1 Pickup
Range: OFF, 20.00 – 70.00 Hz
81D1P =
[59.10]
Level 1 Time Delay
(Hidden if 81D1P = OFF)
Range: 0.03 – 400.00 s
81D1D =
[0.03]
Level 2 Pickup
Range: OFF, 20.00 – 70.00 Hz
81D2P =
[OFF]
Level 2 Time Delay
(Hidden if 81D2P = OFF)
Range: 0.03 – 400.00 s
81D2D =
[Hidden]
Level 3 Pickup
Range: OFF, 20.00 – 70.00 Hz
81D3P =
[OFF]
Level 3 Time Delay
(Hidden if 81D3P = OFF)
Range: 0.03 – 400.00 s
81D3D =
[Hidden]
