Settings Calculation
SIMPRO-100
74 PRIM-2400C
See Section B.3, page 138 for the complete list of
Relay Word bits. Use up to 15 characters to
define the alias, asserted text, and deasserted
text strings. You can use capital letters (A – Z),
numbers
(0 – 9), and the underscore character ( _ ) within
each string. Do not attempt to use a space within
a string because the relay will interpret a space
as the break between two strings. If you wish to
clear a string, simply type NA.
Table 4.45 SET R SER Alias Settings
Setting Prompt RW Bit Alias Asserted Text Deasserted Text
ALIAS1 = STARTING MOTOR_STARTING BEGINS ENDS
ALIAS2 = RUNNING MOTOR_RUNNING BEGINS ENDS
ALIAS3 = STOPPED MOTOR_STOPPED BEGINS ENDS
ALIAS4 = JAMTRIP LOAD_JAM_TRIP PICKUP DROPOUT
ALIAS5 = LOSSTRIP LOAD_LOSS_TRIP PICKUP DROPOUT
ALIAS6 = LOSSALRM LOAD_LOSS_ALARM PICKUP DROPOUT
ALIAS7 = 46UBA UNBALNC_I_ALARM PICKUP DROPOUT
ALIAS8 = 46UBT UNBALNC_I_TRIP PICKUP DROPOUT
ALIAS9 = 49A THERMAL_ALARM PICKUP DROPOUT
ALIAS10 = 49T THERMAL_TRIP PICKUP DROPOUT
ALIAS11 = 47T PHS_REVRSL_TRIP PICKUP DROPOUT
ALIAS12 = SPDSTR SPEED_SW_TRIP PICKUP DROPOUT
ALIAS13 = IN2 DIRECT_TRIP_IN PICKUP DROPOUT
ALIAS14 = SPEEDSW SPEED_SW_IN PICKUP DROPOUT
ALIAS15 = IN5 EMERGNCY_RSTART PICKUP DROPOUT
ALIAS16 = IN1 MOTOR_BREAKER OPEN CLOSED
ALIAS17 = IN4 ACCESS2 ALLOWED PASSWORD_ONLY
ALIAS18 = 0
ALIAS19 = 0
ALIAS20 = 0
