4. Insert the ribbon cable connector of the internal NCS module ① onto the positioner basic
electronics.
Note for installed position feedback module: Reestablish all electrical connections between
the basic electronics and the position feedback module.
5. Put on the supplied module cover. Make sure that the ribbon cable is not trapped.
Note
Module cover
Do not use the standard module cover. The provided module cover has a larger recess.
6. Close the positioner as in the description depending on the device version:
– Closing the standard and and intrinsically safe version (Page 55)
– Closing the device version with "flameproof enclosure" (Page 59)
Result
The module is installed and connected to the basic electronics of the positioner. Now configure
the module with the parameter "1.YFCT (Page 142)".
Installing/mounting
4.5 Installing the optional modules
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 73

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
