Addr. Parameter Setting Options Default Setting Comments
8701 EXTERN TRIP 2 OFF
ON
Block relay
OFF External Trip Function 2
8702 T DELAY 0.00 .. 60.00 sec 1.00 sec Ext. Trip 2 Time Delay
8801 EXTERN TRIP 3 OFF
ON
Block relay
OFF External Trip Function 3
8802 T DELAY 0.00 .. 60.00 sec 1.00 sec Ext. Trip 3 Time Delay
8901 EXTERN TRIP 4 OFF
ON
Block relay
OFF External Trip Function 4
8902 T DELAY 0.00 .. 60.00 sec 1.00 sec Ext. Trip 4 Time Delay
Information List
No. Information Type of
Informa-
tion
Comments
4523 >BLOCK Ext 1 SP >Block external trip 1
4526 >Ext trip 1 SP >Trigger external trip 1
4531 Ext 1 OFF OUT External trip 1 is switched OFF
4532 Ext 1 BLOCKED OUT External trip 1 is BLOCKED
4533 Ext 1 ACTIVE OUT External trip 1 is ACTIVE
4536 Ext 1 picked up OUT External trip 1: General picked up
4537 Ext 1 Gen. TRIP OUT External trip 1: General TRIP
4543 >BLOCK Ext 2 SP >BLOCK external trip 2
4546 >Ext trip 2 SP >Trigger external trip 2
4551 Ext 2 OFF OUT External trip 2 is switched OFF
4552 Ext 2 BLOCKED OUT External trip 2 is BLOCKED
4553 Ext 2 ACTIVE OUT External trip 2 is ACTIVE
4556 Ext 2 picked up OUT External trip 2: General picked up
4557 Ext 2 Gen. TRIP OUT External trip 2: General TRIP
4563 >BLOCK Ext 3 SP >BLOCK external trip 3
4566 >Ext trip 3 SP >Trigger external trip 3
4571 Ext 3 OFF OUT External trip 3 is switched OFF
4572 Ext 3 BLOCKED OUT External trip 3 is BLOCKED
4573 Ext 3 ACTIVE OUT External trip 3 is ACTIVE
4576 Ext 3 picked up OUT External trip 3: General picked up
4577 Ext 3 Gen. TRIP OUT External trip 3: General TRIP
4583 >BLOCK Ext 4 SP >BLOCK external trip 4
4586 >Ext trip 4 SP >Trigger external trip 4
4591 Ext 4 OFF OUT External trip 4 is switched OFF
4592 Ext 4 BLOCKED OUT External trip 4 is BLOCKED
4593 Ext 4 ACTIVE OUT External trip 4 is ACTIVE
4596 Ext 4 picked up OUT External trip 4: General picked up
4597 Ext 4 Gen. TRIP OUT External trip 4: General TRIP
2.10.4
Functions
2.10 External Trip Functions
SIPROTEC 4, 7VE61 and 7VE63, Manual 105
C53000-G1176-C163-3, Edition 10.2017
