Addr. Parameter Setting Options Default Setting Comments
189 EXT. TRIP 4 Disabled
Enabled
Enabled External Trip Function 4
Power System Data 1
The P.System Data 1 include settings associated with all functions rather than a specific synchronizing,
protection, control or monitoring function.
Setting Notes
General
The Power System Data 1 can be changed from the operator or service interface with a personal computer
using DIGSI.
In DIGSI double-click on Settings to display the relevant selection.
Rated System Frequency
The nominal frequency of the system is set in Address 270 Rated Frequency. The factory setting of the
model variant must only be changed if the device is to be used for a purpose other than intended when
ordering.
Command Duration
In address 280 the minimum trip command duration TMin TRIP CMD is set. This duration is valid for all
protection functions which can issue a trip command.
Settings
Addr.
Parameter Setting Options Default Setting Comments
270 Rated Frequency 50 Hz
60 Hz
16,7 Hz
50 Hz Rated Frequency
280 TMin TRIP CMD 0.01 .. 32.00 sec 0.15 sec Minimum TRIP Command Duration
Information List
No.
Information Type of
Informa-
tion
Comments
361 >FAIL:Feeder VT SP >Failure: Feeder VT (MCB tripped)
501 Relay PICKUP OUT Relay PICKUP
511 Relay TRIP OUT Relay GENERAL TRIP command
5588 >FAIL: VT Ua SP >Failure: VT Ua (MCB tripped)
5589 >FAIL: VT Ub SP >Failure: VT Ub (MCB tripped)
5590 >FAIL: VT Uc SP >Failure: VT Uc (MCB tripped)
5591 >FAIL: VT Ud SP >Failure: VT Ud (MCB tripped)
5592 >FAIL: VT Ue SP >Failure: VT Ue (MCB tripped)
5593 >FAIL: VT Uf SP >Failure: VT Uf (MCB tripped)
25007 U1: VI Voltage U1 at switch on
25008 f1: VI Frequency f1 at switch on
25009 U2: VI Voltage U2 at switch on
25010 f2: VI Frequency f2 at switch on
2.1.4
2.1.4.1
2.1.4.2
2.1.4.3
Functions
2.1 General
32 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
