Binary Input
Table D-3 Binary input presettings for all devices and ordering variants
Binary Input Allocated Function Function No. Description
BI1 >Sync Start 222.2011 >Sync. Start of Synchronization
BI2 >Sync Stop 222.2012 >Sync. Stop of Synchronization
BI3 Sy1 active 170.2311 Sync. Function group 1 is active
BI4 >Sy2 active 170.2311 >Sync-group 2 is active
BI5 >Sy3 active 170.2311 >Sync-group 3 is active
BI6 >FAIL: VT Ua 5588 >Failure: VT Ua (MCB tripped)
>FAIL: VT Ub 5589 >Failure: VT Ub (MCB tripped)
>FAIL: VT Uc 5590 >Failure: VT Uc (MCB tripped)
>FAIL: VT Ud 5591 >Failure: VT Ud (MCB tripped)
>FAIL: VT Ue 5592 >Failure: VT Ue (MCB tripped)
>FAIL: VT Uf 5593 >Failure: VT Uf (MCB tripped)
Table D-4 Further binary input presettings for 7VE63
Binäreingang Vorrangierte Funktion Meld.-Nr. BImerkungen
BI7 >Sy4 active 170.2311 >Sync-group 4 is active
BI8 >Sy5 active 170.2311 >Sync-group 5 is active
BI9 >Sy6 active 170.2311 >Sync-group 6 is active
BI10 >Sy7 active 170.2311 >Sync-group 7 is active
BI11 >Sy8 active 170.2311 >Sync-group 8 is active
BI12 Not configured 1 No Function configured
BI13 Not configured 1 No Function configured
BI14 Not configured 1 No Function configured
D.2
Default Settings and Protocol-dependent Functions
D.2 Binary Input
SIPROTEC 4, 7VE61 and 7VE63, Manual 249
C53000-G1176-C163-3, Edition 10.2017
