Siemens SIPROTEC 4 7VE61 User Manual

Functional Scope
Addr. Information Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Disabled Setting Group Change Option
104 FAULT VALUE Disabled
Instant. values
RMS values
RMS values Fault values
140 UNDERVOLTAGE Disabled
Enabled
Enabled Undervoltage Protection
141 OVERVOLTAGE Disabled
Enabled
Enabled Overvoltage Protection
142 FREQUENCY Prot. Disabled
Enabled
Enabled Over / Underfrequency Protection
145 df/dt Protect. Disabled
2 df/dt stages
4 df/dt stages
2 df/dt stages Rate-of-frequency-change protec-
tion
146 VECTOR JUMP Disabled
Enabled
Enabled Jump of Voltage Vector
160 BALANC. (MLFB) Disabled
Enabled
Disabled Balancing Commands (Siemens
only MLFB)
161 SYNC function 1 Disabled
1ph Sync check
3ph Sync check
1,5chan.Synchr
2chan.Synchr.
Disabled SYNC Function group 1
162 SYNC function 2 Disabled
1ph Sync check
3ph Sync check
1,5chan.Synchr
2chan.Synchr.
Disabled SYNC Function group 2
163 SYNC function 3 Disabled
1ph Sync check
3ph Sync check
1,5chan.Synchr
2chan.Synchr.
Disabled SYNC Function group 3
164 SYNC function 4 Disabled
3ph Sync check
1,5chan.Synchr
2chan.Synchr.
Disabled SYNC Function group 4
165 SYNC function 5 Disabled
3ph Sync check
2chan.Synchr.
Disabled SYNC Function group 5
166 SYNC function 6 Disabled
3ph Sync check
2chan.Synchr.
Disabled SYNC Function group 6
167 SYNC function 7 Disabled
3ph Sync check
2chan.Synchr.
Disabled SYNC Function group 7
E.1
Functions, Settings, Information
E.1 Functional Scope
258 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017

Siemens SIPROTEC 4 7VE61 Specifications

General

Product Type	Protection Relay
Rated Current	1 A or 5 A
Current Input	1 A or 5 A
Frequency	50/60 Hz
Display	LCD
Housing	Metal
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Voltage Transformer Inputs	4
Communication Protocols	IEC 61850, Modbus, DNP3
Communication Interfaces	Ethernet, RS485
Protection Functions	Overcurrent
Mounting Type	Panel Mount
