Monitoring possible causes Malfunction Response Indication (No.) Output
Relay monitoring Internal (hardware Indication
Error Relay R1
(25041)
Error Relay R2
(25042)
Synchronizing is
blocked
Plausibility monitorings Configuration errors
Parametrization errors
Indication Sync Fail.Conf.
(222.2331)
Sy1 ParErr
(170.2097)
Synchronizing is
blocked
Offset monitoring Internal (hardware) Indication
Error Offset
(191)
Synchronizing is
blocked
1)
After three unsuccessful restarts, the device is taken out of service.
2)
DOK = "Device Okay" = Ready for service relay drops off, synchronizing protection and control functions are
blocked. Operator communication is still possible
Group indications
Certain indications of the monitoring functions are combined as group indications. These group indications
(disturbance group indication 140, warning group indication 160 and disturbance measured value 181) and
their composition are described in the Appendix E.4 Group Alarms.
Information List
No.
Information Type of
Informa-
tion
Comments
68 Clock SyncError OUT Clock Synchronization Error
140 Error Sum Alarm OUT Error with a summary alarm
160 Alarm Sum Event OUT Alarm Summary Event
170.2097 Sy1 ParErr OUT Sync-group 1: Parameter not plausible
170.2097 Sy2 ParErr OUT Sync-group 2: Parameter not plausible
170.2097 Sy3 ParErr OUT Sync-group 3: Parameter not plausible
170.2097 Sy4 ParErr OUT Sync-group 4: Parameter not plausible
170.2097 Sy5 ParErr OUT Sync-group 5: Parameter not plausible
170.2097 Sy6 ParErr OUT Sync-group 6: Parameter not plausible
170.2097 Sy7 ParErr OUT Sync-group 7: Parameter not plausible
170.2097 Sy8 ParErr OUT Sync-group 8: Parameter not plausible
177 Fail Battery OUT Failure: Battery empty
181 Error A/D-conv. OUT Error: A/D converter
183 Error Board 1 OUT Error Board 1
184 Error Board 2 OUT Error Board 2
185 Error Board 3 OUT Error Board 3
186 Error Board 4 OUT Error Board 4
187 Error Board 5 OUT Error Board 5
188 Error Board 6 OUT Error Board 6
189 Error Board 7 OUT Error Board 7
190 Error Board 0 OUT Error Board 0
191 Error Offset OUT Error: Offset
193 Alarm adjustm. OUT Alarm: Analog input adjustment invalid
2.12.5
Functions
2.12 Supervision
116 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
