No. Information Type of
Informa-
tion
Comments
25049 df = MV Frequency difference df
25050 dα = MV Phase difference dalpha
25051 |dU| = MV Amount of voltage difference |dU|
25052 |df| = MV Amount of frequency difference |df|
25053 |dα| = MV Amount of phase difference |dalpha|
Commissioning
To support commissioning the directions of field rotation of both voltages U1 and U2 are presented in the
measured values display window, as well as the currently active synchronizing fucntion group.
Information List
No. Information Type of
Informa-
tion
Comments
25033 Seq U1 = MV Phase Sequence U1
25034 Seq U2 = MV Phase Sequence U2
25035 SG = MV Active Sync-group
25060 t On = MV Time to next possible switch-on
Min/Max Measurement Setup
Minimum and maximum values are calculated by the 7VE61 and 7VE63 and can be read out with the point of
time (date and time of the last update).
Functional Description
Minimum and maximum values of voltages U1, U2 and ΔU as primary values, of frequencies f1, f2 and Δf, and
the angle difference Δα, each with last update date and time designation. The selected group values are calcu-
lated and displayed. The resetting of the minimum/maximum values takes place automatically for each
successfully starting of a synchronization. Additionally, the minimum/maximum values can be reset via binary
inputs or, in the delivery status of the device, also via the F4 function key.
Information List
No.
Information Type of
Informa-
tion
Comments
- ResMinMax IntSP_Ev Reset Minimum and Maximum counter
399 >U1 MiMa Reset SP >U1 MIN/MAX Buffer Reset
874 U1 Min = MVT U1 (positive sequence) Voltage Minimum
875 U1 Max = MVT U1 (positive sequence) Voltage Maximum
25014 U2min = MVT Voltage U2 Minimum
25015 U2max = MVT Voltage U2 Maximum
25016 f1min = MVT Frequency f1 Minimum
25017 f1max = MVT Frequency f1 Maximum
25018 f2min = MVT Frequency f2 Minimum
25019 f2max = MVT Frequency f2 Maximum
25020 dUmin = MVT Voltage difference dU Minimum
2.14.3
2.14.3.1
2.14.4
2.14.4.1
2.14.4.2
Functions
2.14 Auxiliary Functions
124 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
