Siemens SIPROTEC 4 7VE61 User Manual

General
Analog Inputs/Outputs
Voltage Inputs
Nominal Frequency f
N
50 Hz or 60 Hz (adjustable)
16.7 Hz with version 7VE6***-*****-***1
Secondary nominal voltage 80 V to 125 V
Measuring range 0 V to 200 V
Burden bei 100 V approx. 0.3 VA
Voltage path overload capacity
– Thermal (rms) 230 V continuous
Analog output (for operational measured values)
Nominal Range DC 0 mA to 20 mA
Operating Range DC 0 mA to 22.5 mA
Connection for flush-mounted case Rear panel, mounting location „B“ or/and „D“,
9-pin DSUB female connector
For Panel Surface-Mounted Case At the terminal on the case bottom or/and at the housing top
Max. Burden 350 Ω
Auxiliary Voltage
DC Voltage
Voltage supply using integrated converter
Rated auxiliary U
AUX
– DC 24 V/48 V DC 60 V/110 V/125 V
Permissible Voltage Ranges DC 19 V to 58 V DC 48 V to 150 V
Rated auxiliary U
AUX
– DC 110 V/125 V/220 V/250 V
Permissible Voltage Ranges DC 88 V to 300 V
Permissible AC ripple voltage,
Peak to peak, IEC 60 255–11
≤ 15 % of the auxiliary voltage
Power Input quiescent energized
7VE61 approx. 5 W approx. 9.5 W
7VE63 approx. 5.5 W approx. 14 W
Bridging time for failure/short circuit (not in
energized operation)
≥ 50 ms at U ≥ DC 48 V (U
A,N
= 24 V/48 V)
≥ 50 ms at U ≥ DC 110 V (U
A,N
= 60 V..125 V)
≥ 20 ms at U ≥ DC 24 V (U
A,N
= 24 V/48 V)
≥ 20 ms at U ≥ DC 60 V (U
A,N
= 60 V..125 V)
Alternating Voltage
Voltage supply using integrated converter
Nominal Auxiliary Voltage U
AUX
AC 115 V to 230 V (50/60 Hz)
Permissible voltage range AC 92 V to 276 V
Power Input quiescent energized
7VE61 approx. 9 VA approx. 21 VA
4.1
4.1.1
4.1.2
Technical Data
4.1 General
194 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
