Addr. Parameter Setting Options Default Setting Comments
6180 f BALANCING OFF
Pulse
OFF Frequency balancing
6181 T f PULS MIN 10 .. 1000 ms 20 ms Minimum pulse duration for f
balancing
6182 T f PULS MAX 1.00 .. 32.00 sec 1.00 sec Maximum pulse duration for f
balancing
6183 df2 / dt 0.05 .. 5.00 Hz/s 1.00 Hz/s df/dt of the controller
6184 T f PAUSE 0.00 .. 32.00 sec 5.00 sec Transient time of the f-controller
6185 Δf SET POINT -1.00 .. 1.00 Hz 0.04 Hz Set point for frequency balancing
6186A SMOOTHING f 1 .. 100 1 Smoothing factor for the
frequency
6187 KICK PULSE OFF
ON
ON Release of kick pulses
6188A Δf KICK -0.10 .. 0.10 Hz 0.04 Hz df for the kick pulse
6189A T SW-ON MIN 0.2 .. 1000.0 sec 5.0 sec Min time to switch-on without
balancing
Information List
No. Information Type of
Informa-
tion
Comments
170.0001 >Sy1 activ SP >Sync-group 1 activate
170.0050 Sy1 Error OUT Sync-group 1: Error
170.0051 Sy1 BLOCK OUT Sync-group 1 is BLOCKED
170.2007 Sy1 Ctrl SP Sync-group 1 Measuring req. of Control
170.2008 >BLOCK Sy1 SP >BLOCK Sync-group 1
170.2022 Sy1 measu. OUT Sync-group 1: measurement in progress
170.2050 U1 = MV U1
170.2051 f1 = MV f1
170.2052 U2 = MV U2
170.2053 f2 = MV f2
170.2054 dU = MV dU
170.2055 df = MV df
170.2056 dα = MV dalpha
170.2101 Sy1 OFF OUT Sync-group 1 is switched OFF
170.2300 Sync CloseRel 1 OUT Sync. Release of Close Command 1
170.2301 Sync CloseRel 2 OUT Sync. Release of Close Command 2
170.2311 Sy1 active OUT Sync. Function group 1 is active
170.2312 Sy1 on OUT Sync-group 1 is switched on
SYNC General
Setting Notes
General
In the following tables are shown parameter and messages which are not specially assigned to one of the 8
synchronization groups but they apply for the synchronization function in general.
2.2.2.3
2.2.3
2.2.3.1
Functions
2.2 Paralleling Functions
78 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
