Addr. Parameter Setting Options Default Setting Comments
4207 f2 PICKUP 40.00 .. 65.00 Hz 57.00 Hz f2 Pickup
4208 f2 PICKUP 12.00 .. 20.00 Hz 15.80 Hz f2 PICKUP
4209 T f2 0.00 .. 100.00 sec 6.00 sec T f2 Time Delay
4210 f3 PICKUP 40.00 .. 65.00 Hz 49.50 Hz f3 Pickup
4211 f3 PICKUP 40.00 .. 65.00 Hz 59.50 Hz f3 Pickup
4212 f3 PICKUP 12.00 .. 20.00 Hz 16.50 Hz f3 PICKUP
4213 T f3 0.00 .. 100.00 sec 20.00 sec T f3 Time Delay
4214 f4 PICKUP 40.00 .. 65.00 Hz 52.00 Hz f4 Pickup
4215 f4 PICKUP 40.00 .. 65.00 Hz 62.00 Hz f4 Pickup
4216 f4 PICKUP 12.00 .. 20.00 Hz 17.20 Hz f4 PICKUP
4217 T f4 0.00 .. 100.00 sec 10.00 sec T f4 Time Delay
4218 THRESHOLD f4 automatic
f>
f<
automatic Handling of Threshold Stage f4
4219 Umin 10.0 .. 125.0 V 65.0 V Minimum Required Voltage for
Operation
4220 MEAS. INPUT Ua
Ub
Uc
Ud
Ue
Uf
Ua Used Measuring Input
Information List
No.
Information Type of
Informa-
tion
Comments
5203 >BLOCK Freq. SP >BLOCK frequency protection
5206 >BLOCK f1 SP >BLOCK frequency protection stage f1
5207 >BLOCK f2 SP >BLOCK frequency protection stage f2
5208 >BLOCK f3 SP >BLOCK frequency protection stage f3
5209 >BLOCK f4 SP >BLOCK frequency protection stage f4
5211 Freq. OFF OUT Frequency protection is switched OFF
5212 Freq. BLOCKED OUT Frequency protection is BLOCKED
5213 Freq. ACTIVE OUT Frequency protection is ACTIVE
5215 Freq UnderV Blk OUT Frequency protection undervoltage Blk
5232 f1 picked up OUT Frequency protection: f1 picked up
5233 f2 picked up OUT Frequency protection: f2 picked up
5234 f3 picked up OUT Frequency protection: f3 picked up
5235 f4 picked up OUT Frequency protection: f4 picked up
5236 f1 TRIP OUT Frequency protection: f1 TRIP
5237 f2 TRIP OUT Frequency protection: f2 TRIP
5238 f3 TRIP OUT Frequency protection: f3 TRIP
5239 f4 TRIP OUT Frequency protection: f4 TRIP
2.6.4
Functions
2.6 Frequency Protection
SIPROTEC 4, 7VE61 and 7VE63, Manual 91
C53000-G1176-C163-3, Edition 10.2017
