Settings
Addr. Parameter Setting Options Default Setting Comments
401 WAVEFORMTRIGGER Save w. Pickup
Save w. TRIP
Start w. TRIP
Start w. TRIP Waveform Capture
403 MAX. LENGTH 0.30 .. 10.00 sec 10.00 sec Max. length of a Waveform
Capture Record
404 PRE. TRIG. TIME 0.05 .. 5.00 sec 5.00 sec Captured Waveform Prior to
Trigger
405 POST REC. TIME 0.05 .. 2.00 sec 2.00 sec Captured Waveform after Event
406 BinIn CAPT.TIME 0.10 .. 10.00 sec 10.00 sec Capture Time via Binary Input
Information List
No. Information Type of
Informa-
tion
Comments
- FltRecSta IntSP Fault Recording Start
4 >Trig.Wave.Cap. SP >Trigger Waveform Capture
30053 Fault rec. run. OUT Fault recording is running
Time Setup
The integrated date/clock management enables the exact timely assignment of events e.g., those in the
operational messages and fault messages or in the lists of the minimum/maximum values.
Functional Description
The time can be influenced by
•
internal RTC (Real Time Clock)
•
external synchronization sources (e.g. DCF77, IRIG B)
•
external minute pulses via binary input.
i
i
NOTE
Upon delivery of the device the internal clock RTC is always set by default as synchronization source,
regardless of whether the device is equipped with a system interface or not. If the time synchronization is
to use an external source, this must be selected.
The procedure for changing the synchronization source is described in detail in the SIPROTEC 4- System
Description.
The following operating modes can be selected:
No.
Operating Mode Description
1 Intern Internal synchronization using RTC (default)
2 IEC 60870-5-103 External synchronization via system interface (IEC 60870-5-103)
3 PROFIBUS DP External synchronization using PROFIBUS interface
4 Zeitzeichen IRIG B External synchronization using IRIG B
(telegramm format IRIG-B000)
5 Zeitzeichen DCF77 External synchronization using DCF 77
6 Zeitzeichen Sync.-Box External synchronization using the SIMEAS-Synch.Box time signal
7 Impuls über Binäreingang External synchronization with pulse via binary input
2.14.8.3
2.14.8.4
2.14.9
2.14.9.1
Functions
2.14 Auxiliary Functions
128 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
