Siemens SIPROTEC 4 7VE61 User Manual

No. Information Type of
Informa-
tion
Comments
- SynchClock IntSP_Ev Clock Synchronization
- HWTestMod IntSP Hardware Test Mode
- Distur.CFC OUT Disturbance CFC
1 Not configured SP No Function configured
2 Non Existent SP Function Not Available
3 >Time Synch SP_Ev >Synchronize Internal Real Time Clock
5 >Reset LED SP >Reset LED
15 >Test mode SP >Test mode
16 >DataStop SP >Stop data transmission
51 Device OK OUT Device is Operational and Protecting
52 ProtActive IntSP At Least 1 Protection Funct. is Active
55 Reset Device OUT Reset Device
56 Initial Start OUT Initial Start of Device
67 Resume OUT Resume
69 DayLightSavTime OUT Daylight Saving Time
70 Settings Calc. OUT Setting calculation is running
71 Settings Check OUT Settings Check
72 Level-2 change OUT Level-2 change
73 Local change OUT Local setting change
110 Event Lost OUT_Ev Event lost
113 Flag Lost OUT Flag Lost
125 Chatter ON OUT Chatter ON
301 Pow.Sys.Flt. OUT Power System fault
302 Fault Event OUT Fault Event
320 Warn Mem. Data OUT Warn: Limit of Memory Data exceeded
321 Warn Mem. Para. OUT Warn: Limit of Memory Parameter exceeded
322 Warn Mem. Oper. OUT Warn: Limit of Memory Operation exceeded
323 Warn Mem. New OUT Warn: Limit of Memory New exceeded
545 PU Time VI Time from Pickup to drop out
546 TRIP Time VI Time from Pickup to TRIP
EN100-Modul 1
Functional Description
An Ethernet Ethernet EN100-Module allows for the integration of the 7VE61 and 7VE63 into 100 Mbit
Ethernet communication networks used by process control and automation systems according to the IEC
61850 protocols. This standard enables integrated inter-relay communication without using gateways or
protocol converters. This allows open and interoperable use of SIPROTEC 4 devices even in heterogeneous
environments. In addition to the process control integration of the device, this interface can also be used for
communication with DIGSI and for interrelay communication via GOOSE messaging.
2.1.2
2.1.2.1
Functions
2.1 General
28 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
