Siemens SIPROTEC 4 7VE61 User Manual

Binary Output
Table D-5 Output relay presettings for all devices and ordering variants
Binary Output Allocated Function Function No. Description
BO1 Sync CloseRel 1 170.2300 Sync. Release of Close Command 1
BO2 Sync CloseRel 2 170.2301 Sync. Release of Close Command 2
BO3 Sy1 measu. 170.2022 Sync-group 1: measurement in
progress
Sy2 measu. 170.2022 Sync-group 2 measurement in
progress
Sy3 measu. 170.2022 Sync-group 3 measurement in
progress
Sy4 measu. 170.2022 Sync-group 4 measurement in
progress
Sy5 measu. 170.2022 Sync-group 5 measurement in
progress
Sy6 measu. 170.2022 Sync-group 6 measurement in
progress
Sy7 measu. 170.2022 Sync-group 7 measurement in
progress
Sy8 measu. 170.2022 Sync-group 8 measurement in
progress
BO4 Sy1 Error 170.0050 Sync-group 1: Error
Sy2 Error 170.0050 Sync-group 2 Error
Sy3 Error 170.0050 Sync-group 3 rror
Sy4 Error 170.0050 Sync-group 4 Error
Sy5 Error 170.0050 Sync-group 5 Error
Sy6 Error 170.0050 Sync-group 6 Error
Sy7 Error 170.0050 Sync-group 7 Error
Sy8 Error 170.0050 Sync-group 8 Error
BO5 Sync ON-Sig 25064 Sync: ON - Signal
BO6 Sync U2 up 223.2325 Sync: increase voltage U2
BO7 Sync U2 down 223.2324 Sync: decrease voltage U2
BO8 Sync f2 up 223.2327 Sync: increase frequency f2
BO9 Sync f2 down 223.2326 Sync: decrease frequency f2
Table D-6 Further output relay presettings for 7VE63
Binary Output Allocated Function Function No. Description
BO12 .. 19 Not configured 1 No Function configured
D.3
Default Settings and Protocol-dependent Functions
D.3 Binary Output
250 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
