LEDs
Table D-1 LED Indication Presettings
LEDs Allocated Function Function No. Description
LED1 Sync CloseRel 1 170.2300 Sync. Release of Close Command 1
LED2 Sync CloseRel 2 170.2301 Sync. Release of Close Command 2
LED3 Sy1 measu. 170.2022 Sync-group 1: measurement in
progress
Sy2 measu. 170.2022 Sync-group 2 measurement in
Sy3 measu. 170.2022 Sync-group 3 measurement in
Sy4 measu. 170.2022 Sync-group 4 measurement in
Sy5 measu. 170.2022 Sync-group 5 measurement in
Sy6 measu. 170.2022 Sync-group 6 measurement in
Sy7 measu. 170.2022 Sync-group 7 measurement in
Sy8 measu. 170.2022 Sync-group 8 measurement in
LED4 Sy1 Error 170.0050 Sync-group 1: Error
Sy2 Error 170.0050 Sync-group 2 Error
Sy3 Error 170.0050 Sync-group 3 Error
Sy4 Error 170.0050 Sync-group 4 Error
Sy5 Error 170.0050 Sync-group 5 Error
Sy6 Error 170.0050 Sync-group 6 Error
Sy7 Error 170.0050 Sync-group 7 Error
Sy8 Error 170.0050 Sync-group 8 Error
LED5 Sync. fdiff ok 222.2031 Sync. Frequency difference (fdiff) okay
LED6 Sync. Udiff ok 222.2030 Sync. Voltage difference (Udiff) okay
LED7 Sync. α ok 222.2032 Sync. Angle difference (adiff) okay
Table D-2 Additional preset LED displays for 7VE63
LEDs Allocated Function Function No. Description
LED8 Sync U2 up 223.2325 Sync: increase voltage U2
LED9 Sync U2 down 223.2324 Sync: decrease voltage U2
LED10 Sync f2 up 223.2327 Sync: increase frequency f2
LED11 Sync f2 down 223.2326 Sync: decrease frequency f2
LED12 Sync f syn 1 222.2332 Sync:Synchronization cond. f1
Sync f syn 2 222.2332 Sync:Synchronization cond. f2
LED13 SyncSeq U1 fail 25039 Sync: Failure phase sequence U1
SyncSeq U2 fail 25040 Sync: Failure phase sequence U2
LED14 Error Sum Alarm 140 Error with a summary alarm
Alarm Sum Event 160 Alarm Summary Event
D.1
Default Settings and Protocol-dependent Functions
D.1 LEDs
248 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
