Radio frequency electromagnetic field, individual frequencies
IEC 60255-22-3,
IEC 61000-4-3,
Amplitude-modulated
Class III: 10 V/m
80/160/450/900 MHz 80 % AM 1 kHz; duty cycle >
10 s
Fast transient disturbance variables / burst
IEC 60255-22-4 and
IEC 61000-4-4, Class IV
4 kV; 5/50 ns; 5 kHz; burst length = 15 ms; repetition
rate 300 ms; both polarities; R
i
= 50 Ω; Test duration
1 min
High energy surge voltages (SURGE),
IEC 61000-4-5 Installation Class 3
Impuls: 1,2/50 µs
Auxiliary voltage common mode: 2 kV; 12 Ω; 9 µF
diff. mode: 1 kV; 2 Ω; 18 µF
Measuring inputs, binary inputs and relay outputs common mode: 2 kV; 42 Ω; 0,5 µF
diff. mode: 1 kV; 42 Ω; 0,5 µF
Line conducted HF, amplitude module
IEC 61000-4-6, Class III
10 V; 150 kHz to 80 MHz; 80 % AM; 1 kHz
Power system frequency magnetic field
IEC 61000-4-8, Class IV
IEC 60255-6
30 A/m continuous; 300 A/m for 3 s; 50 Hz
0,5 mT; 50 Hz
Oscillatory Surge Withstand Capability
IEEE Std C37.90.1
2,5 kV (peak); 1 MHz; τ = 15 µs;
400 Surges per s; Test duration 2 s; R
i
= 200 Ω
Fast Transient Surge Withstand Cap.
IEEE Std C37.90.1
4 kV; 5/50 ns; 5 kHz; burst length = 15 ms; repetition
rate 300 ms; both polarities; R
i
= 50 Ω; test duration
1 min
Radiated Electromagnetic Interference
IEEE Std C37.90.2
35 V/m; 25 MHz to 1000 MHz
Damped oscillations
IEC 60694, IEC 61000-4-12
2,5 kV (peak value), polarity alternating 100 kHz,
1 MHz, 10 MHz and 50 MHz,
R
i
= 200 Ω
EMC Tests For Noise Emission (Type Test)
Standards:
EN 61000-6-3 (generic standard)
Radio Noise Voltage to Lines, Only Power Supply Voltage
IEC-CISPR 22
150 kHz to 30 MHz
MHz Limit Class B
Radio Noise Field Strength IEC-CISPR 11 30 MHz to 1000 MHz MHz Limit Class A
Mechanical Tests
Vibration and Shock Resistance during Stationary Operation
Standards:
IEC 60255-21 and IEC 60068
Oscillation
IEC 60255-21-1, Class 2
IEC 60068-2-6
Sinusoidal
10 Hz to 60 Hz: ± 0,075 mm amplitude;
60 Hz to 150 Hz: 1 g Acceleration
Frequency sweep 1 octave/min
20 cycles in 3 orthogonal axes
Shock
IEC 60255-21-2, Class 1
IEC 60068-2-27
Semi-sinusoidal
5 g acceleration, duration 11 ms,
each 3 shocks (in both directions of the 3 axes)
4.1.6
Technical Data
4.1 General
200 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
