Addr. Information Setting Options Default Setting Comments
168 SYNC function 8 Disabled
3ph Sync check
2chan.Synchr.
Disabled SYNC Function group 8
173 ANALOGOUTPUT B1 Disabled
Enabled
Disabled Analog Output B1 (Port B)
174 ANALOGOUTPUT B2 Disabled
Enabled
Disabled Analog Output B2 (Port B)
175 ANALOGOUTPUT D1 Disabled
Enabled
Disabled Analog Output D1 (Port D)
176 ANALOGOUTPUT D2 Disabled
Enabled
Disabled Analog Output D2 (Port D)
185 THRESHOLD Disabled
Enabled
Enabled Threshold Supervision
186 EXT. TRIP 1 Disabled
Enabled
Enabled External Trip Function 1
187 EXT. TRIP 2 Disabled
Enabled
Enabled External Trip Function 2
188 EXT. TRIP 3 Disabled
Enabled
Enabled External Trip Function 3
189 EXT. TRIP 4 Disabled
Enabled
Enabled External Trip Function 4
Functions, Settings, Information
E.1 Functional Scope
SIPROTEC 4, 7VE61 and 7VE63, Manual 259
C53000-G1176-C163-3, Edition 10.2017
