Siemens SIPROTEC 4 7VE61 User Manual

Addr. Parameter Setting Options Default Setting Comments
161 SYNC function 1 Disabled
1ph Sync check
3ph Sync check
1,5chan.Synchr
2chan.Synchr.
Disabled SYNC Function group 1
162 SYNC function 2 Disabled
1ph Sync check
3ph Sync check
1,5chan.Synchr
2chan.Synchr.
Disabled SYNC Function group 2
163 SYNC function 3 Disabled
1ph Sync check
3ph Sync check
1,5chan.Synchr
2chan.Synchr.
Disabled SYNC Function group 3
164 SYNC function 4 Disabled
3ph Sync check
1,5chan.Synchr
2chan.Synchr.
Disabled SYNC Function group 4
165 SYNC function 5 Disabled
3ph Sync check
2chan.Synchr.
Disabled SYNC Function group 5
166 SYNC function 6 Disabled
3ph Sync check
2chan.Synchr.
Disabled SYNC Function group 6
167 SYNC function 7 Disabled
3ph Sync check
2chan.Synchr.
Disabled SYNC Function group 7
168 SYNC function 8 Disabled
3ph Sync check
2chan.Synchr.
Disabled SYNC Function group 8
173 ANALOGOUTPUT B1 Disabled
Enabled
Disabled Analog Output B1 (Port B)
174 ANALOGOUTPUT B2 Disabled
Enabled
Disabled Analog Output B2 (Port B)
175 ANALOGOUTPUT D1 Disabled
Enabled
Disabled Analog Output D1 (Port D)
176 ANALOGOUTPUT D2 Disabled
Enabled
Disabled Analog Output D2 (Port D)
185 THRESHOLD Disabled
Enabled
Enabled Threshold Supervision
186 EXT. TRIP 1 Disabled
Enabled
Enabled External Trip Function 1
187 EXT. TRIP 2 Disabled
Enabled
Enabled External Trip Function 2
188 EXT. TRIP 3 Disabled
Enabled
Enabled External Trip Function 3
Functions
2.1 General
SIPROTEC 4, 7VE61 and 7VE63, Manual 31
C53000-G1176-C163-3, Edition 10.2017
