Siemens SIPROTEC 4 7VE61 User Manual

Addr. Parameter Setting Options Default Setting Comments
7321 ANALOGOUTPUT B2 U1 [%]
f1 [%]
U2 [%]
f2 [%]
ΔU [%]
Δf [%]
Δα [%]
|ΔU| [%]
|Δf| [%]
|Δα| [%]
ΔU [%] Analog Output B2 (Port B)
7322 MIN. VALUE(B2) -200.00 .. 100.00 % 0.00 % Minimum Percentage Output
Value (B2)
7323 MIN. OUTPUT(B2) 0 .. 10 mA 4 mA Minimum Current Output Value
(B2)
7324 MAX. VALUE(B2) 10.00 .. 200.00 % 100.00 % Maximum Percentage Output
Value (B2)
7325 MAX. OUTPUT(B2) 10 .. 22 mA 20 mA Maximum Current Output Value
(B2)
7331 ANALOGOUTPUT D1 U1 [%]
f1 [%]
U2 [%]
f2 [%]
ΔU [%]
Δf [%]
Δα [%]
|ΔU| [%]
|Δf| [%]
|Δα| [%]
ΔU [%] Analog Output D1 (Port D)
7332 MIN. VALUE(D1) -200.00 .. 100.00 % 0.00 % Minimum Percentage Output
Value (D1)
7333 MIN. OUTPUT(D1) 0 .. 10 mA 4 mA Minimum Current Output Value
(D1)
7334 MAX. VALUE(D1) 10.00 .. 200.00 % 100.00 % Maximum Percentage Output
Value (D1)
7335 MAX. OUTPUT(D1) 10 .. 22 mA 20 mA Maximum Current Output Value
(D1)
7341 ANALOGOUTPUT D2 U1 [%]
f1 [%]
U2 [%]
f2 [%]
ΔU [%]
Δf [%]
Δα [%]
|ΔU| [%]
|Δf| [%]
|Δα| [%]
ΔU [%] Analog Output D2 (Port D)
7342 MIN. VALUE(D2) -200.00 .. 100.00 % 0.00 % Minimum Percentage Output
Value (D2)
7343 MIN. OUTPUT(D2) 0 .. 10 mA 4 mA Minimum Current Output Value
(D2)
Functions
2.11 AnalogOutputs
110 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
