Max. angle error 3° for Δf ≤ 1 Hz at f
N
= 50/60 Hz
3° for Δf ≤ 0.3 Hz at f
N
= 16.7 Hz
5° for Δf ≥ 1 Hz at f
N
= 50/60 Hz
5° for Δf ≥ 0.3 Hz at f
N
= 16.7 Hz
Synchronous/asynchronous thresholds 0.01 Hz to 0.04 Hz
Tolerances 5 mHz
Circuit breaker operating time 10 ms to 1000 ms Increments 1 ms
Times
Minimal measuring time for the already
selected function groups
approx. 10 ms at f
N
= 50/60 Hz
approx. 30 ms at f
N
= 16.7 Hz
Minimal measuring time without previous
selected function groups
approx. 80 ms at f
N
= 50/60 Hz
approx. 240 ms at f
N
= 16.7 Hz
Maximum transmission time after starting 0.01 s to 1200.00 s; ∞ Increments 0.01 s
Closing time of the circuit breaker 10 ms to 1000 ms; ∞ Increments 1 ms
Minimum switching order duration 0.01 s to 10.00 s Increments 0.01 s
Voltages monitoring time 0.0 s to 60.0 s Increments 0.1 s
Tolerance of all timers 1 % of setting value or 10 ms
Consideration of the Transformer Tapping
Tap number for secondary nominal voltage
-62 to 62 Increments 1
Difference between 2 increments in percentage 0.00 % to 20.00 % Increments 0.01 %
Technical Data
4.2 Paralleling Functions
204 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
