Task Level
Limit in TICKS
1)
SFS_BEARB (Interlocking) 10000
1)
When the sum of TICKS of all blocks exceeds the limits before-mentioned, an error message is output by CFC.
Processing times in TICKS required by the individual elements
Individual Element Number of TICKS
Module, basic requirement 5
Each input from the 3rd additional input for generic blocks 1
Connection to an input signal 6
Connection to an output signal 7
Additional for each chart 1
Arithmetic ABS_VALUE 5
ADD 26
SUB 26
MUL 26
DIV 54
SQUARE_ROOT 83
Basis logic AND 5
CONNECT 4
DYN_OR 6
NAND 5
NEG 4
NOR 5
OR 5
RISE_DETECT 4
X_OR 5
Information status SI_GET_STATUS 5
CV_GET_STATUS 5
DI_GET_STATUS 5
MV_GET_STATUS 5
SI_SET_STATUS 5
DI_SET_STATUS 5
MV_SET_STATUS 5
ST_AND 5
ST_OR 5
ST_NOT 5
Memory D_FF 5
D_FF_MEMO 6
RS_FF 4
RS_FF_MEMO 4
SR_FF 4
SR_FF_MEMO 4
Control commands BOOL_TO_CO 5
BOOL_TO_IC 5
CMD_INF 4
CMD_INF_EXE 4
CMD_CHAIN 34
CMD_CANCEL 3
Technical Data
4.11 User-defined functions (CFC)
SIPROTEC 4, 7VE61 and 7VE63, Manual 215
C53000-G1176-C163-3, Edition 10.2017
