Addr. Parameter Function Setting Options Default Setting Comments
4101 OVERVOLTAGE Overvoltage OFF
ON
Block relay
OFF Overvoltage Protection
4102 U> Overvoltage 30.0 .. 200.0 V 115.0 V U> Pickup
4103 T U> Overvoltage 0.00 .. 60.00 sec 3.00 sec T U> Time Delay
4104 U>> Overvoltage 30.0 .. 200.0 V 130.0 V U>> Pickup
4105 T U>> Overvoltage 0.00 .. 60.00 sec 0.50 sec T U>> Time Delay
4106A U> DOUT RATIO Overvoltage 0.90 .. 0.99 0.95 U>, U>> Drop Out Ratio
4107 MEAS. INPUT Overvoltage Ua
Ub
Uc
Ud
Ue
Uf
Ua Used Measuring Input
4201 O/U FREQUENCY Frequency Prot. OFF
ON
Block relay
OFF Over / Under Frequency
Protection
4202 f1 PICKUP Frequency Prot. 40.00 .. 65.00 Hz 48.00 Hz f1 Pickup
4203 f1 PICKUP Frequency Prot. 40.00 .. 65.00 Hz 58.00 Hz f1 Pickup
4204 f1 PICKUP Frequency Prot. 12.00 .. 20.00 Hz 16.10 Hz f1 PICKUP
4205 T f1 Frequency Prot. 0.00 .. 600.00 sec 1.00 sec T f1 Time Delay
4206 f2 PICKUP Frequency Prot. 40.00 .. 65.00 Hz 47.00 Hz f2 Pickup
4207 f2 PICKUP Frequency Prot. 40.00 .. 65.00 Hz 57.00 Hz f2 Pickup
4208 f2 PICKUP Frequency Prot. 12.00 .. 20.00 Hz 15.80 Hz f2 PICKUP
4209 T f2 Frequency Prot. 0.00 .. 100.00 sec 6.00 sec T f2 Time Delay
4210 f3 PICKUP Frequency Prot. 40.00 .. 65.00 Hz 49.50 Hz f3 Pickup
4211 f3 PICKUP Frequency Prot. 40.00 .. 65.00 Hz 59.50 Hz f3 Pickup
4212 f3 PICKUP Frequency Prot. 12.00 .. 20.00 Hz 16.50 Hz f3 PICKUP
4213 T f3 Frequency Prot. 0.00 .. 100.00 sec 20.00 sec T f3 Time Delay
4214 f4 PICKUP Frequency Prot. 40.00 .. 65.00 Hz 52.00 Hz f4 Pickup
4215 f4 PICKUP Frequency Prot. 40.00 .. 65.00 Hz 62.00 Hz f4 Pickup
4216 f4 PICKUP Frequency Prot. 12.00 .. 20.00 Hz 17.20 Hz f4 PICKUP
4217 T f4 Frequency Prot. 0.00 .. 100.00 sec 10.00 sec T f4 Time Delay
4218 THRESHOLD f4 Frequency Prot. automatic
f>
f<
automatic Handling of Threshold
Stage f4
4219 Umin Frequency Prot. 10.0 .. 125.0 V 65.0 V Minimum Required Voltage
for Operation
4220 MEAS. INPUT Frequency Prot. Ua
Ub
Uc
Ud
Ue
Uf
Ua Used Measuring Input
4501 df/dt Protect. df/dt Protect. OFF
ON
Block relay
OFF Rate-of-frequency-change
protection
Functions, Settings, Information
E.2 Settings
SIPROTEC 4, 7VE61 and 7VE63, Manual 261
C53000-G1176-C163-3, Edition 10.2017
