Addr. Parameter Function Setting Options Default Setting Comments
4603 T DELTA PHI Vector Jump 0.00 .. 60.00 sec 0.00 sec T DELTA PHI Time Delay
4604 T RESET Vector Jump 0.10 .. 60.00 sec 5.00 sec Reset Time after Trip
4605A U MIN Vector Jump 10.0 .. 125.0 V 80.0 V Minimal Operation Voltage
U MIN
4606A U MAX Vector Jump 10.0 .. 170.0 V 130.0 V Maximal Operation Voltage
U MAX
4607A T BLOCK Vector Jump 0.00 .. 60.00 sec 0.10 sec Time Delay of Blocking
4609 MEAS. INPUT Vector Jump Ua
Ub
Uc
Ud
Ue
Uf
Ua Used Measuring Input
6001 COM. TESTSYNC. SYNC General OFF
ON
OFF Test synchronization
(Commissioning)
6101 Synchronizing SYNC function 1 ON
OFF
OFF Synchronizing Function
6102 SyncSD SYNC function 1 OBJVERWparaMEIN-
STELL
none synchronizable switching
device
6103 Umin SYNC function 1 20 .. 125 V 90 V Minimum voltage limit:
Umin
6104 Umax SYNC function 1 20 .. 140 V 110 V Maximum voltage limit:
Umax
6105 U< SYNC function 1 1 .. 60 V 5 V Threshold U1, U2 without
voltage
6106 U> SYNC function 1 20 .. 140 V 80 V Threshold U1, U2 with
voltage
6107 SYNC U1<U2> SYNC function 1 YES
NO
NO ON-Command at U1< and
U2>
6108 SYNC U1>U2< SYNC function 1 YES
NO
NO ON-Command at U1> and
U2<
6109 SYNC U1<U2< SYNC function 1 YES
NO
NO ON-Command at U1< and
U2<
6111A TSUP VOLTAGE SYNC function 1 0.0 .. 60.0 sec 0.1 sec Supervision time Dead
Line / Dead Bus
6112 T-SYN. DURATION SYNC function 1 0.01 .. 1200.00 sec 1200.00 sec Maximum duration of
synchronism-check
6113 PHASE SEQUENCE SYNC function 1 NO
L1 L2 L3
L1 L3 L2
NO Phase sequence check
6120 T-CB close SYNC function 1 10 .. 1000 ms 2147483647 ms Closing (operating) time of
CB
6121 Balancing U1/U2 SYNC function 1 0.50 .. 2.00 1.00 Balancing factor U1/U2
6122A ANGLE ADJUSTM. SYNC function 1 0 .. 359 ° 0 ° Angle adjustment (trans-
former)
6124 VT Un1, primary SYNC function 1 0.10 .. 999.99 kV 15.75 kV VT nominal voltage U1,
primary
6125 VT Un2, primary SYNC function 1 0.10 .. 999.99 kV 15.75 kV VT nominal voltage U2,
primary
Functions, Settings, Information
E.2 Settings
SIPROTEC 4, 7VE61 and 7VE63, Manual 263
C53000-G1176-C163-3, Edition 10.2017
