Addr. Parameter Function Setting Options Default Setting Comments
6174 T U PAUSE SYNC function 1 0.00 .. 32.00 sec 5.00 sec Transient time of the U-
controller
6175A SMOOTHING U SYNC function 1 1 .. 100 1 Smoothing factor for the
voltage
6176A (U/Un) / (f/fn) SYNC function 1 1.00 .. 1.40 1.10 Maximum permissible over-
excitation
6180 f BALANCING SYNC function 1 OFF
Pulse
OFF Frequency balancing
6181 T f PULS MIN SYNC function 1 10 .. 1000 ms 20 ms Minimum pulse duration for
f balancing
6182 T f PULS MAX SYNC function 1 1.00 .. 32.00 sec 1.00 sec Maximum pulse duration
for f balancing
6183 df2 / dt SYNC function 1 0.05 .. 5.00 Hz/s 1.00 Hz/s df/dt of the controller
6184 T f PAUSE SYNC function 1 0.00 .. 32.00 sec 5.00 sec Transient time of the f-
controller
6185 Δf SET POINT SYNC function 1 -1.00 .. 1.00 Hz 0.04 Hz Set point for frequency
balancing
6186A SMOOTHING f SYNC function 1 1 .. 100 1 Smoothing factor for the
frequency
6187 KICK PULSE SYNC function 1 OFF
ON
ON Release of kick pulses
6188A Δf KICK SYNC function 1 -0.10 .. 0.10 Hz 0.04 Hz df for the kick pulse
6189A T SW-ON MIN SYNC function 1 0.2 .. 1000.0 sec 5.0 sec Min time to switch-on
without balancing
6201 Synchronizing SYNC function 2 ON
OFF
OFF Synchronizing Function
6202 SyncSD SYNC function 2 OBJVERWparaMEIN-
STELL
none synchronizable switching
device
6203 Umin SYNC function 2 20 .. 125 V 90 V Minimum voltage limit:
Umin
6204 Umax SYNC function 2 20 .. 140 V 110 V Maximum voltage limit:
Umax
6205 U< SYNC function 2 1 .. 60 V 5 V Threshold U1, U2 without
voltage
6206 U> SYNC function 2 20 .. 140 V 80 V Threshold U1, U2 with
voltage
6207 SYNC U1<U2> SYNC function 2 YES
NO
NO ON-Command at U1< and
U2>
6208 SYNC U1>U2< SYNC function 2 YES
NO
NO ON-Command at U1> and
U2<
6209 SYNC U1<U2< SYNC function 2 YES
NO
NO ON-Command at U1< and
U2<
6211A TSUP VOLTAGE SYNC function 2 0.0 .. 60.0 sec 0.1 sec Supervision time Dead
Line / Dead Bus
6212 T-SYN. DURATION SYNC function 2 0.01 .. 1200.00 sec 1200.00 sec Maximum duration of
synchronism-check
6213 PHASE SEQUENCE SYNC function 2 NO
L1 L2 L3
L1 L3 L2
NO Phase sequence check
Functions, Settings, Information
E.2 Settings
SIPROTEC 4, 7VE61 and 7VE63, Manual 265
C53000-G1176-C163-3, Edition 10.2017
