Addr. Parameter Function Setting Options Default Setting Comments
6584 T f PAUSE SYNC function 5 0.00 .. 32.00 sec 5.00 sec Transient time of the f-
controller
6585 Δf SET POINT SYNC function 5 -1.00 .. 1.00 Hz 0.04 Hz Set point for frequency
balancing
6586A SMOOTHING f SYNC function 5 1 .. 100 1 Smoothing factor for the
frequency
6587 KICK PULSE SYNC function 5 OFF
ON
ON Release of kick pulses
6588A Δf KICK SYNC function 5 -0.10 .. 0.10 Hz 0.04 Hz df for the kick pulse
6589A T SW-ON MIN SYNC function 5 0.2 .. 1000.0 sec 5.0 sec Min time to switch-on
without balancing
6601 Synchronizing SYNC function 6 ON
OFF
OFF Synchronizing Function
6602 SyncSD SYNC function 6 OBJVERWparaMEIN-
STELL
none synchronizable switching
device
6603 Umin SYNC function 6 20 .. 125 V 90 V Minimum voltage limit:
Umin
6604 Umax SYNC function 6 20 .. 140 V 110 V Maximum voltage limit:
Umax
6605 U< SYNC function 6 1 .. 60 V 5 V Threshold U1, U2 without
voltage
6606 U> SYNC function 6 20 .. 140 V 80 V Threshold U1, U2 with
voltage
6607 SYNC U1<U2> SYNC function 6 YES
NO
NO ON-Command at U1< and
U2>
6608 SYNC U1>U2< SYNC function 6 YES
NO
NO ON-Command at U1> and
U2<
6609 SYNC U1<U2< SYNC function 6 YES
NO
NO ON-Command at U1< and
U2<
6611A TSUP VOLTAGE SYNC function 6 0.0 .. 60.0 sec 0.1 sec Supervision time Dead
Line / Dead Bus
6612 T-SYN. DURATION SYNC function 6 0.01 .. 1200.00 sec 1200.00 sec Maximum duration of
synchronism-check
6613 PHASE SEQUENCE SYNC function 6 NO
L1 L2 L3
L1 L3 L2
NO Phase sequence check
6620 T-CB close SYNC function 6 10 .. 1000 ms 2147483647 ms Closing (operating) time of
CB
6621 Balancing U1/U2 SYNC function 6 0.50 .. 2.00 1.00 Balancing factor U1/U2
6622A ANGLE ADJUSTM. SYNC function 6 0 .. 359 ° 0 ° Angle adjustment (trans-
former)
6624 VT Un1, primary SYNC function 6 0.10 .. 999.99 kV 15.75 kV VT nominal voltage U1,
primary
6625 VT Un2, primary SYNC function 6 0.10 .. 999.99 kV 15.75 kV VT nominal voltage U2,
primary
6626 Unom SECONDARY SYNC function 6 80 .. 125 V 100 V Rated Secondary Voltage
(Ph-Ph)
6627 T CLS CMD MIN SYNC function 6 0.01 .. 10.00 sec 0.10 sec Min close command time of
the CB
Functions, Settings, Information
E.2 Settings
274 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
