No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
25002 Frequency fb (fb =) Measurement 134 156 No 9 8 CFC CD DD
25003 Frequency fc (fc =) Measurement 134 156 No 9 9 CFC CD DD
25004 Frequency fd (fd =) Measurement 134 156 No 9 10 CFC CD DD
25005 Frequency fe (fe =) Measurement 134 156 No 9 11 CFC CD DD
25006 Frequency ff (ff =) Measurement 134 156 No 9 12 CFC CD DD
25014 Voltage U2 Minimum (U2min =) Min/Max meter - - - - - CFC CD DD
25015 Voltage U2 Maximum (U2max =) Min/Max meter - - - - - CFC CD DD
25016 Frequency f1 Minimum (f1min =) Min/Max meter - - - - - CFC CD DD
25017 Frequency f1 Maximum (f1max =) Min/Max meter - - - - - CFC CD DD
25018 Frequency f2 Minimum (f2min =) Min/Max meter - - - - - CFC CD DD
25019 Frequency f2 Maximum (f2max =) Min/Max meter - - - - - CFC CD DD
25020 Voltage difference dU Minimum
(dUmin =)
Min/Max meter - - - - - CFC CD DD
25021 Voltage difference dU Maximum
(dUmax =)
Min/Max meter - - - - - CFC CD DD
25022 Frequency difference df Minimum
(dfmin =)
Min/Max meter - - - - - CFC CD DD
25023 Frequency difference df Maximum
(dfmax =)
Min/Max meter - - - - - CFC CD DD
25024 Angel difference dalpha Minimum
(dαmin =)
Min/Max meter - - - - - CFC CD DD
25025 Angel difference dalpha Maximum
(dαmax =)
Min/Max meter - - - - - CFC CD DD
25033 Phase Sequence U1 (Seq U1 =) Commis-
sioning
134 156 No 9 13 CFC CD DD
25034 Phase Sequence U2 (Seq U2 =) Commis-
sioning
134 156 No 9 14 CFC CD DD
25035 Active Sync-group (SG =) Commis-
sioning
134 156 No 9 15 CFC CD DD
25044 Voltage U1 (U1 =) Measurement 130 1 No 9 1 CFC CD DD
25045 Voltage U2 (U2 =) Measurement 130 1 No 9 2 CFC CD DD
25046 Frequency f1 (f1 =) Measurement 130 1 No 9 3 CFC CD DD
25047 Frequency f2 (f2 =) Measurement 130 1 No 9 4 CFC CD DD
25048 Voltage difference dU (dU =) Measurement 130 1 No 9 5 CFC CD DD
25049 Frequency difference df (df =) Measurement 130 1 No 9 6 CFC CD DD
25050 Phase difference dalpha (dα =) Measurement 130 1 No 9 7 CFC CD DD
25051 Amount of voltage difference |dU|
(|dU| =)
Measurement - - - - - CFC CD DD
25052 Amount of frequency difference |
df| (|df| =)
Measurement - - - - - CFC CD DD
25053 Amount of phase difference |
dalpha| (|dα| =)
Measurement - - - - - CFC CD DD
Functions, Settings, Information
E.5 Measured Values
312 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
