Siemens SITRANS FUE1010 IP65 NEMA 4X User Manual

Connecting
5.4 Programming the Transmitter
FUE1010 IP65 NEMA 4X
52 Operating Instructions, 12/2014, A5E03086491-AC
3. Pre-programmed Pipe Size and relevant pipe parameters will appear in menu cells. Press
<Right Arrow> and scroll to desired pipe size. Press <ENTER>. Enter dimensions
manually if pre-programmed dimensions do not match application.
Note
The DN sizes listed in the [Select Pipe Size] menu option list are referenced to DIN Table
2448. After select
ing pipe size, check pipe OD and wall thickness for correct dimensions.
4. Press the <Left Arrow> and return to the [Channel Setup] menu.
Select Liquid Class
1. Press the <Down Arrow> and scroll to [Application Data].
2. Press the <Right Arrow> to select [Liquid Class].
3. Press the <Right Arrow> again and scroll to desired liquid.
4. Press <ENTER> to save selection.
①
Select from list.
