Command lists
10.2 Command lists
SIWAREX WP231
Manual, 07/2014, A5E31238908A-02
141
82 Perform auto-
matic calibration
Calculation of scale characteristic using the load cell parameters
from data record 10. The calculated characteristic is entered
directly in data records 3 and 4 and thus immediately enabled
following execution of the command. The scale must be empty
when the command is executed.
P
83 Perform calibra-
tion check
The command calculates the theoretical digital values in•relation
to the calibration weights using the load cell parameters from data
record 10 and the adjustment weights 0, 1 and 2 from data record
3. These theoretical digits are output in data record 4. The func-
tion can be used to carry out a plausibility check for the calibration
digits in data record 3 which were determined when calibrated
using standard weights.
Table 10- 2 Commands 400 ... 449; log commands, statistics, logbook
401 Generate log Log current parameters relevant to the calibra-
tion
405 Delete log memory Delete all logs P
440 Delete the logbook. Only permitted in non-
calibrated state.
441 Reserve
Table 10- 3 Commands 450 ... 499: Trace commands
451 Trace RAM on Start permanent tracing
452 Trace RAM off Stop permanent tracing
453 Single trace RAM Create single trace (current state)
454 Delete trace RAM Delete tracing memory.
Table 10- 4 Commands 700 to 899: HMI display switching
701 Increased resolution Enable increased resolution on the main dis-
play and the SecureDisplay (x 10), for duration
of 5 s
705 Display current tare weight Display current tare weight on main display and
SecureDisplay
710 Activate standard display Enable standard display gross/net (main dis-
play and SecureDisplay)
714 N process value (no write protec-
tion)
Display net process weight on main display,
only permitted if OIML is not set as the regula-
tion code (main display and SecureDisplay)
P
