Scale parameters and functions
8.3 DR 3 calibration parameters
SIWAREX WP231
Manual, 07/2014, A5E31238908A-02
65
Variable
Note
Type
Length
(bytes)
Read/write
protection
Default
Min.
Max.
Modbus
registers
Gross identi-
fier header
Maximum length and actual
length of string for unit of weight
UBYTE[2] 2 rwP 02,02 - - 1014
Gross identi-
fier
(Page 68)
Abbreviation of gross
(B or G), only one byte is used!
CHAR[2] 2 rwP "B" "B" "G" 1015
Reserve 1 Reserve USHORT 2 rw 0 - - 1016
Code for
regulations
(Page 68)
0: None
1: OIML R76 (available soon)
USHORT 2 rwP 0 - - 1017
Minimum
weighing
range
(Page 69)
Minimum number d USHORT 2 rwP 20 0 65535 1018
Reserve Reserve USHORT 2 rw 0 - - 1019
Maximum
weighing
range
(Page 69)
1)
Maximum weight FLOAT 4 rwP 100 > weigh-
ing_range
_min
maximum
number
range
1020
Calibration
weights 0, 1,
2 and cali-
bration digits
0, 1, 2
(Page 69)
Calibration weight 0
1)
(usually
the zero point)
FLOAT 4 rwP 0 1 maximum
number
range
1022
Calibration weight 1
1)
FLOAT 4 rwP 100 1 maximum
number
range
1024
Calibration weight 2 FLOAT 4 rwP 0 1 maximum
number
range
1026
Calibration digits 0 determined
during calibration with calibra-
tion weight 0
FLOAT 4 rwP 0 0 1000000 1028
Calibration digits 1 determined
during calibration with calibra-
tion weight 1
FLOAT 4 rwP 2000 0 1000000 1030
Calibration digits 2 determined
during calibration with calibra-
tion weight 2
FLOAT 4 rwP 0 0 1000000 1032
Scale interval
(Page 69)
1)
Weighing range1 scale interval
(1*10**k, 2*10**k, 5*10**k]; k: -3
… 2)
FLOAT 4 rwP 0.1 0.001 50 1034
Zero by
power-on
(Page 69)
Zero by power-on
0: Zero by power-on off
1: Zero by power-on on
BIT 0 rw 0 0 1 1036.16
Zero by
power-on
when tare ≠
0 (Page 70)
Zero by power-on when tare ≠ 0
0: Zero by power-on disabled
when tare ≠ 0
1: Zero by power-on when tare
≠ 0
BIT 0 rw 0 0 1 1036.15
Automatic
zero adjust-
ment
(Page 70)
0: Autom. zero adjustment off
1: Autom. zero adjustment on
BIT 0 rw 0 0 1 1036.14
Subtractive /
additive tare
device
(Page 70)
Subtractive / additive tare de-
vice
0: Subtractive tare device
1: Additive tare device
BIT 0 rwP 0 0 1 1036.13
