Scale parameters and functions
8.3 DR 3 calibration parameters
SIWAREX WP231
66 Manual, 07/2014, A5E31238908A-02
Variable
Note
Type
Length
(bytes)
Read/write
protection
Default
Min.
Max.
Modbus
registers
Weight simu-
lation
(Page 71)
Weight simulation
0: Weight simulation disabled
1: Weight simulation value of
DR16 applied
Weight simulation is always
disabled when write protection
is enabled
BIT 0 rwP 0 0 1 1036.12
Bit 5 Bit 5: Reserve BIT 0 rw 0 0 1 1036.11
Bit 6 Bit 6: Reserve BIT 0 rw 0 0 1 1036.10
Bit 7 Bit 7: Reserve BIT 0 rw 0 0 1 1036.9
Bit 8 Bit 8: Reserve BIT 0 rw 0 0 1 1036.8
Bit 9 Bit 9: Reserve BIT 0 rw 0 0 1 1036.7
Bit 10 Bit 10: Reserve BIT 0 rw 0 0 1 1036.6
Bit 11 Bit 11: Reserve BIT 0 rw 0 0 1 1036.5
Bit 12 Bit 12: Reserve BIT 0 rw 0 0 1 1036.4
Bit 13 Bit 13: Reserve BIT 0 rw 0 0 1 1036.3
Bit 14 Bit 14: Reserve BIT 0 rw 0 0 1 1036.2
Bit 15 Bit 15: Reserve BIT 2 rw 0 0 1 1036.1
Decimal
places for
process
values
(Page 71)
0: No rounding
1: Rounding to 1 decimal place
2: Rounding to 2 decimal places
3: Rounding to 3 decimal places
4: Rounding to 4 decimal places
5: Rounding to 5 decimal places
6: Rounding to 6 decimal places
USHORT 2 rwP 0 0 6 1037
Maximum
tare load
(Page 71)
Range of the subtractive tare
device
[in % of max. weighing range]
(must not exceed 100% with
regulation code "OIML")
FLOAT 4 rwP 0 0 250 1038
Maximum
negative zero
setting limit
(power-on)
(Page 71)
Negative range of the zero by
power-on device [in % of maxi-
mum weighing range]
(positive + negative zero setting
limit must not exceed 20% with
country code "OIML")
FLOAT 4 rwP 1.0 0 100.0 1040
Maximum
positive zero
setting limit
(power-on)
(Page 71)
Positive range of the zero by
power-on device [in % of maxi-
mum weighing range]
(positive + negative zero setting
limit must not exceed 20% with
country code "OIML")
FLOAT 4 rwP 3.0 0 100.0 1042
Maximum
negative zero
setting limit
(semi-
automatical-
ly) (Page 72)
Negative range of the semi-
automatic zeroing [in % of
maximum weighing range]
(positive + negative zero setting
limit must not exceed 4% with
country code "OIML")
FLOAT 4 rwP 10.0 0 100.0 1044
Maximum
positive zero
setting limit
(semi-
automatical-
ly) (Page 72)
Positive range of the semi-
automatic zeroing [in % of
maximum weighing range]
(positive + negative zero setting
limit must not exceed 4% with
country code "OIML")
FLOAT 4 rwP 3.0 0 100.0 1046
