98
Item Quantity Material number Designation Description
1
2 1 WVN501-10.5x1.5 O-ring Seal for pressure switch
13 1 MKF.U016 Level switch, cpl. For fluid grease in 2- and 3-liter unit (NC contact)
1 MKF.U116 Level switch, cpl. For fluid grease in 6-liter unit (NC contact)
1 MKU.U015 Fill level switch, cpl. For oil in 2- and 3-liter unit (NO-contact)
1 MKU.U016 Fill level switch, cpl. For oil in 2- and 3-liter unit (NC contact)
1 MKU.U115 Fill level switch, cpl. For oil in 6-liter unit (NO-contact)
1 MKU.U116 Fill level switch, cpl. For oil in 6-liter unit (NC contact)
14 4 911-205-161 Cheese-head screw Reservoir fastening for 2-liter
6 911-205-181 Cheese-head screw Z1 Reservoir fastening for 3- and 6-liter
15 1 993-000-169 Reservoir, cpl. 2-liter plastic reservoir with seal
1 B3.U180 Reservoir, 3-liter 3-liter metal reservoir with seal
1 BK3.U147 Reservoir, 3-liter 3-liter plastic reservoir with seal
1 BK6.U180 Reservoir, 6-liter 6-liter plastic reservoir with seal
16 1 898-660-056 Cover Cover for 2-liter unit
1 898-660-052 Cover Cover for 3- and 6-liter unit
17 1 MKU.U009 Filler socket, cpl. For oil (with strainer)
1 MKU.U019 Filler socket, cpl. For oil (with strainer), 3-liter lid
1 MKF.U009 Filler socket, cpl. For fluid grease (without strainer)
1 MKF.U019 Filler socket, cpl. For fluid grease (without strainer), 3-liter lid
18 * 1 IG38-30-I+XXX 2) Control unit For time-dependent control (only for 3- and 6-liter units)
1 IZ38-30-I+XXX 2) Control unit For load-dependent control (only for 3- and 6-liter units)
1 IGZ36-20-S6-I+XXX 2) Control unit Pulse generator/pulse counter (only for 3- and 6-liter units)
1 IG54-20-S4-I+XXX 2) Control unit Pulse generator (only for MKL units)
19 * 1 79-990-033 Cable socket
20* 1 79-990-206 Device protection fuse For 24 V DC units
*) Not shown
1) Add voltage code to material number when ordering 230 V AC (+428); 115 V AV (+429)
2) Add voltage code to material number when ordering 230/115 V AC (+471); 24 V DC (+472)
EN
11. Spare parts
