REMOTE BUS INTERFACE: RS-232
71
System Parameter Editing Commands and Companion Queries
These commands are used to modify the system parameters for the instrument. These
commands require a parameter value to be included with the command.
Command
Name
Value
SDH{1|0}
SDH?
DUT HV Setup ON/OFF
1=On, 0=Off
SPR {1|0}
SPR?
PLC Remote ON/OFF
1=On, 0=Off
SSI {1|0}
SSI?
Single Step ON/OFF
1=On, 0=Off
SF {1|0}
SF?
Fail Stop ON/OFF
1=On, 0=Off
SAL <value>
SAL?
Alarm Level
1-9
SL {1|0}
SL?
System Lock
1=On, 0=Off
SML {1|0}
SML?
System Memory Lock
1=On, 0=Off
Query Commands
These query commands will retrieve data from the instrument. These commands include
functions for retrieving test data, test results and remote hardware.
Command
Name
Value
TD?
List Testing Data
Data from test in Process
RD <step number>?
Result Data
Query
1-3
RR?
Read Reset Query
1=Open, 0=Closed
RI?
Read Interlock
Query
1=Open, 0=Closed
LS?
List Step
Parameters
LS <step number>?
List Step
Parameters by
step number
step number = 1-10
TD?
Read the active data being displayed on the LCD display while the test is in process. It
will also read the last data taken when the test sequence has completed. Each parameter is
separated by commas and includes step number, test type, test status, and metering. The
syntax for this command response is {memory - step, test type, status, meter 1, meter 2,
meter 3}. Each meter will contain both the value and the units.
RD <step number>?
Read the results for an individual step. The step number is the actual step number that has
been saved within the file, not the order of which the steps were executed. For example if
