18.1.17 Functional Test of CMV Mode
Step 41 For the functional test set the following parameters in the CMV preview mode:
BPM..................... 20
Ti..........................1 sec.
PEEP...................5mbar
PIP.......................20 mbar
FiO
2
.....................21%
After pressing the confirm button the user will be presented with the CMV
screen.
Check that:
TTV
plus
................is set to OFF. (This button will not appear
when functional testing with no flow sensor fitted).
