SLE SLE5000 Model J - Page 267

(Model J) Page 267
4 190 N6631/2216 ..Serial controller PCB 1
Attaching Parts
195 H3091 ..Nut (M3) 2
200 H3094 ..Washer, shakeproof (M3) 2

205 H0305/36 ..Spacer 2
Attaching Parts
210 H3106 ..Screw (M3 x 6mm) 2
215 H3094 ..Washer, shakeproof (M3) 2

220 W0346 ..Cable, assembly 1

225 A1260/01 ..Computer/Display PCB carrier assy. 1

230 M0484/03 .AA battery 2

235 A0763/02/M .Control & Monitor PCB
Note: See “A0763/02/M Monitor and
control board” on page 56.
1

240 N6631/14 .Display assembly
(See items 190-200)
1
Attaching Parts
245 H3106 ..Screw (M3 x 6mm) 2
250 H3110 ..Screw (M3 x 10mm) 2
255 H3091 .Nut (M3) 2
260 H3094 ..Washer, shakeproof (M3) 2

265 T1310/02 .Strap,Connector 1
270 M0630 .Pad, Foam. (50mm) 1
Attaching Parts
275 H3108 ..Screw (M3 x 8mm) 2
280 H3094 ..Washer, shakeproof (M3) 2

Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
