4 285 N6631/02 .Liquid Crystal display
(Supplier: L.G.Philips)
(Part Nº LB121S02-A2)
1
290 N6631/05 .Touch screen 1
Attaching Parts
295 M0907 ..Tape AR

300 T0253/02 ..Spacer, block 2
Attaching Parts
305 H3106 ..Screw (M3 x 6mm) 2

310 L5007-1005 .Screen Mounting Assembly
(See items 230-260)
1
Attaching Parts
315 H4108 ..Screw (M4 x 8mm) 4
320 H4094 ..Washer, shakeproof (M4) 4

325 T1310 .Tie Bar 2
Attaching Parts
330 H3108 ..Screw (M3 x 8mm) 6
335 H3094 ..Washer, shakeproof (M3) 6

340 L0011 .Dampener Assembly 1
-345 M0434 .Cable tie 1
Attaching Parts
350 H3108 ..Screw (M3 x 8mm) 2
355 H3094 ..Washer, shakeproof (M3) 2

360 M0902/50 .Fan assembly 1
Attaching Parts
365 H3908 ..Screw, Skt Cap. (M3 x 8mm) 4
370 H3094 ..Washer, shakeproof (M3) 4

375 M0305/29 .Spacer 2
Attaching Parts
380 H3208 .Screw (M3 x 8mm) 2

Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
