Page 270 (Model J)
4 490 M0306 (1) ..Screw 2
495 M0306 (2) ..Nut 2
500 M0306 (3) ..Washer 2
505 A0761 .Transducer PCB Assembly 1
Attaching Parts
510 M0305/36 ..Pillar 6
515 H3206 ..Screw (M3 x 6mm) 6
520 H3091 ..Nut (M3) 6
525 H3094 ..Washer, shakeproof (M3) 6
530 N0280/75 .Tube AR
-535 M0434 .Cable tie 4
540 N2520 .Y Piece Connector 1
545 M0904 .PCB Runner 2
Attaching Parts
-550 M0752 ..Adhesive AR
555 T1243 .Locking Block, PCB 1
Attaching Parts
560 H3208 ..Screw (M3 x 8mm) 2
565 M0901 .Battery, Back-up 2
575 W0332 .Link Cable, Battery 1
Attaching Parts
580 H4212 ..Screw (M4 x 12mm) 4
585 T1192 ..Boss, battery mounting 4
590 L5007-1007 .Battery/Bracket Assembly
(See items 545-555)
1
Attaching Parts
595 H4110 ..Screw (M4 x 10mm) 2
600 H4094 ..Washer, shakeproof (M4) 2
Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
To Next Page
