SLE SLE5000 Model J - Page 271

(Model J) Page 271
4 605 L5007/001/001 PCB Bracket Runner Assembly
(See items 560-600)
1
Attaching Parts
610 H3210 ..Screw (M3 x 10mm) 2

615 M0901 .Battery, Back-up 1
620 T1254 .Bracket, Battery 1
Attaching Parts
625 H5110 ..Screw (M5 x 10mm) 2

630 M0904 .PCB Runner 2
-635 M0752 ..Adhesive AR
640 T1249 .Bracket, PCB Runner 1
645 N2096 .Buzzer 1
650 M0434/01 .Cable tie 1
655 T1244 .PCB Spacer 2
Attaching Parts
660 H3108 ..Screw (M3 x 8mm) 2
665 H3094 ..Washer, shakeproof (M3) 2

670 P0451/01 .Connector, Mains Inlet 1
Attaching Parts
675 H3210 ..Screw (M3 x 10mm) 2
680 H3091 ..Nut (M3) 2
685 H3210 ..Washer, shakeproof (M3) 2

690 W0325 .Mains power loom 1
695 M0767 .Core, Ferrite 1
-700 M0660 .Pad, adhesive 1
Attaching Parts
705 H4216 ..Screw (M4 x 16mm) 1
710 H4091 ..Nut (M4) 3
715 H4094 ..Washer, shakeproof (M4) 3

Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
