SLE SLE5000 Model J - Page 272

Page 272 (Model J)
- Item Not illustrated
4 720 N6616 (1) .Pneumatic connector
(Supplier: West Group)
2
Attaching Parts
725 N6616 (2) ..Nut, Locking
(Supplier: West Group)
4

730 M0706/02 .label, earth 1

735 O0431 (1) .Switch, Push Button 1
Attaching Parts
740 O0431 (2) .Nut, locking 1

745 M0856 .Clamp, cable tie 2
Attaching parts
750 H3206 ..Screw (M3 x 6mm) 2
755 H3091 ..Nut (M3) 2
760 H3094 ..Washer, shakeproof (M3) 2

765 M0903 .Speaker 1
Attaching parts
770 H3212 ..Screw (M3 x 12mm) 4
775 T0209/02 ..Washer, shouldered
780 H3091 ..Nut (M3) 4
785 H3094 ..Washer, shakeproof (M3) 4

790 W0348 .Cable, Ribbon RS232 connector 1
Attaching parts
795 M0306 (1) ..Screw 2
800 M0306 (2) ..Nut 2
805 M0306 (3) ..Washer 2

810 M0913 .Fuse holder, main body 1
815 M0779/10 .Fuse, 10amp 1

820 M0802/103 .Label, Fuse (Issue 2) 1

825 T1188/01 .Chassis, Electronic Unit 1

Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
