YELLOW Alarm -
“MIN. VOL. ALARM”
High Minute Vol (34)
Low Minute Vol (37)
Indicates either high or low
minute volume alarm has
occurred.
YELLOW Alarm -
“PATIENT LEAK”
Pat. Leak Alarm (35)
YELLOW Alarm -
“LOW TIDAL VOL.”
Low Tidal Vol. (36)
YELLOW Alarm -
“POWER FAIL”
Main Power Fail (41)
YELLOW Alarm -
“O2 CELL FAIL”
O2 Cell Disconn (43)
O2 Cell Exhausted (45)
O2 Cell Cal Fail (46)
O2 Cell Cal Reqd. (44)
Indicates one of four alarm
conditions associated with the
oxygen cell.
YELLOW Alarm -
“O2 CONC ALARM”
High O2 Level (47)
Low O2 Level (48)
Indicates an oxygen
concentration alarm.
