Somat eDAQ lite
Normalize
Select the normalize tap coefficients option to normalize all tap coefficients for a unity
gain.
7.5 Tracking Computed Channels
7.5.1 Max Track
The Max Track channel generates an output channel that tracks the maximum value
of the input channel. A logical channel specified as a trigger can reset the output
channel tracking.
Input Channel
The input channel data type must be 32-bit float or 16-bit integer.
Output Data Type
The output data type is the same as the input data type.
Enable Triggered Reset
Select the triggered reset option to enable triggered resets of the tracker.
NOTE
Resetting the tracker sets the maximum value to the current sample value.
Trigger Channel
If using the reset enable feature, specify the desired trigger channel.
Trigger Mode
If using the reset enable feature, specify one of three available trigger reset modes.
7.5.2 Min Track
The Min Track channel generates an output channel that tracks the minimum value of
the input channel. A logical channel specified as a trigger can reset the output channel
tracking.
Input Channel
The input channel data type must be 32-bit float or 16-bit integer.
Output Data Type
The output data type is the same as the input data type.
Trigger Mode Description
When TRUE Reset when the trigger channel is TRUE.
On FALSE-TRUE edge Reset when the trigger transitions from FALSE to TRUE.
On TRUE-FALSE edge Reset on the sample after the trigger channel transitions from
TRUE to FALSE.
