Figure 2-5: Improper vehicle battery connection for switching battery to ground.
2.4 Data Storage
2.4.1 Data Formats
The eDAQ lite offers two formats for storing recorded data: SIE and SIF. Select which
data format to use in the TCE network setup window. A summary of the differences
between the SIE and SIF data formats follow.
For more information on using SIE and SIF in TCE, see “Default data option” on
page 52.
NOTE
For all storage media options, the eDAQ lite stores raw SIF test data and related
information in a set of individual component files referred to as SIC files using a fixed
naming convention (i.e., sif00000.sic, sif00001.sic, sif00002.sic, etc.). To view these
8GJKENG
$CVVGT[


8GJKENGHKTGYCNN
8
8
DNCEM
TGF
4GOQVG2QYGT
8
8
DNCEM
TGF
/CKP2QYGT
G&#3
5#%'294
2QYGT
8GJKENGHKTGYCNN
8
DNCEM

QYGT
/C
5#%'2
SIE SIF
Unlimited file size Files limited to slightly less than 4 GB
eDAQ lite can store multiple data files eDAQ lite can only store one data file
Data is readable during testing Data is readable only after test completion
No support for RAM disk data storage RAM disk data storage available
No support for max bursts mode for the Burst
History DataMode
Max bursts mode available for the Burst
History DataMode
No support for accumulating histogram data
across test runs
Support for accumulating histogram data
across test runs
