Histogram Mode
Select one of three available histogramming modes.
Hysteresis
Enter the desired hysteresis level for the peak valley processing algorithm.
Number of Bins
Specify the desired number of bins up to 500 for the histogram. For the range-mean
and the to-from histogram modes, the value is for both histogram dimensions. The
total number of bins per dimension is the user-specified number of bins plus two for
underflow and overflow bins. For the range-mean and to-from histogram modes which
have two dimensions, the total number of bins for the DataMode is the product of the
total number of bins for each dimension.
8.4.4 Time at Level (One Dimensional)
The Time at Level (1D) DataMode stores one-dimension Time at Level histograms in
the output data file. Specify multiple input channels to generate multiple
one-dimensional Time at Level data channels.
Input Channel
The input channel data type must be 32-bit float or 16-bit integer. If using the
user-defined bins option, the input channel data type must be 32-bit float.
Number of Bins
Specify the desired number of bins. The total number of bins is the user-specified
number of bins plus two for underflow and overflow bins.
8.4.5 Time at Level (Multidimensional)
The Time at Level (mD) DataMode stores a multiple-dimension Time at Level
histogram in the output data file.
Input Channel
The input channel data type must be 32-bit float or 16-bit integer. If using the
user-defined bins option, the input channel data type must be 32-bit float.
Number of Bins
Select the desired number of bins for each dimension. Separate the individual bin
count specifications by spaces or commas. The total number of bins for each
dimension is the user-specified number of bins plus two for underflow and overflow
bins. The total number of bins for the DataMode is the product of the total number of
bins for each dimension. For example, defining the number of bins for four input
channels as 10, 20, 5 and 15 results in 31416 (i.e. 12*22*7*17) total number of bins.
Mode Description
Range-Mean Accumulate cycle counts in bins with both a cycle range dimension
and a cycle mean value dimension.
Range Only Accumulate cycle counts in bins with only a cycle range dimension.
To-From Accumulate cycle counts in bins with both a to dimension and a from
dimension. The eDAQ
lite assigns to and from designations to the first
reversal instead of the second on which the cycle actually closes.
