Somat eDAQ lite
18 Cable Resistances
The following table lists measured resistances for a selection of Somat cables.
Cable
Length
(m) Order Number
Resistance
(Ohms)
Transducer Cable 2 1-SAC-TRAN-MP-2-2 0.27
10 1-SAC-TRAN-MP-10-2 1.25
Extension Cable 0.4 1-SAC-EXT-MF-0.4-2 0.06
2 1-SAC-EXT-MF-2-2 0.23
5 1-SAC-EXT-MF-5-2 0.61
10 1-SAC-EXT-MF-10-2 1.20
15 1-SAC-EXT-MF-15-2 1.84
