Somat eDAQ
lite
56
I2773-4.4 en
3.2.5 Scope and Spectrum Display
The scope and spectrum display options allow changes in the color schemes and
other presentation parameters for both run-time displays and the original displays
used when a test is not running. For more information on scope and spectrum
displays, see “Viewing Channel Displays” on page 72.
Trace color
Select the desired color for drawing signal trace vectors.
Screen color
Select either black or white as the background screen color.
Auto scale mode
Automatically scale the y-axis. As spectrum displays always use auto scale, this option
is only applicable to scope displays.
Show grid lines
Activate visible grid lines on the plot.
Show prerun value
Start the display showing the prerun value when present. This option is only applicable
to the scope displays.
3.2.6 Run-Time Display
Use the run-time display preferences to set a default run-time display type and
configure display options for the bar and strip chart display. For more information on
run-time displays, see “Viewing Channel Displays” on page 72.
Display mode
Select the preferred display mode to use as the default when opening a run-time
display.
NOTE
To modify the display parameters for scope and spectrum plots, use the scope and
spectrum display preferences. The digital readout display has no display options.
Trace/bar color
Select the desired color for drawing the signal traces or bars.
Screen color
Select either black or white as the background screen color.
Strip chart plot mode
Select the desired behavior when the signal trace reaches the right edge of the plot.
